Description

Control panel:

• Temperature adjustment range: 40-110°C
• Humidity adjustment range: 20-95rH
• Duration: family saunas 1–6 h, public saunas in apartment buildings 1–12 h. For longer working hours, consult the importer / manufacturer.
• Delay time adjustment range: 0-18 h
• Lighting and fan control
• Data cable length: 5 m (10 m extension cable available, maximum length 30 m)

Power supply:

• Supply voltage: 400 V 3N ~
• Lighting control, max. power: 100 W, 230 V 1N ~
• Fan control, max. power: 100W, 230V 1N ~
• Maximum. load from case remote control, electric heater 11kW
• Maximum load from the control panel, to the steamer 3kW

Sensor:

• The temperature sensor WX232 is equipped with a switchable, overheat protection and temperature sensor NTC thermistor (22 kΩ / T = 25 ° C)

Technical data:

• Dimensions: width (mm):  147
• Dimensions: height (mm):  50
• Dimensions: depth (mm) : 30
• Weight, (kg) : 1.9
• Adjustable temperature, min.-max. (°C):  40 – 110
• Heater power, max. (kW):  11
• Heating time, (h) : 12
• Setting the switch-on time, (h) : 0 – 18
• Maximum reading, (°C) : 110
• Additional information : 400V 3N
